Product Description
Our self-developed series of welding industrial robots feature high-rigidity six-axis mechanical designs integrated with advanced motion control algorithms and intelligent welding process packages, specifically engineered for high-precision, high-efficiency welding applications. these robots are ideal for diverse industrial welding scenarios.
Core Technical Advantages
-
High-Precision Motion Control
-
Repeat positioning accuracy: ±0.05mm
-
Equipped with high-resolution encoders (23-bit absolute)
-
Supports TCP auto-calibration and seam tracking
-
Intelligent Welding System
-
Integrated MIG/MAG/TIG/laser welding processes
-
Proprietary welding expert database (500+ process parameters)
-
Real-time penetration monitoring and adaptive parameter adjustment
-
Robust & Durable Design
-
IP67 protection rating for harsh industrial environments
-
Key component lifespan: 50,000 hours
-
Modular structure for easy maintenance
